What to do if CO sensor 2 is not working in Brink Test Equipment?
If you're experiencing issues with the CO sensor 2 in your Brink Test Equipment, here's what you can do: First, remove the voltage from the appliance. Next, inspect the sensor wiring. If there's damage, replace the wiring or the sensor itself. Finally, restore the voltage to the appliance. The fault should automatically reset.
How to fix a faulty humidity sensor on Brink Air 70?
If the humidity sensor in your Brink Test Equipment isn't functioning correctly, follow these steps: First, disconnect the voltage from the appliance. Then, examine the sensor wiring for any issues. Replace the wiring or the sensor if necessary. After that, reapply the voltage to the appliance, and the fault should reset automatically.
How to troubleshoot the preheater on Brink Air 70 Test Equipment?
To troubleshoot the preheater in your Brink Test Equipment, follow these steps: First, remove the voltage from the appliance. Check the preheater wiring for any issues. Replace the wiring or the preheater if necessary. Finally, put the voltage back on the appliance. The fault should automatically reset.
What to do if Plus PCB is defective in Brink Test Equipment?
If you have a defective Plus PCB (locking fault) in your Brink Test Equipment, try this: First, take the voltage from the appliance. Check the connection to the Plus PCB. If needed, replace the Plus PCB. Then, put the voltage back on the appliance, and the fault should automatically reset.
How to resolve a 4-way switch closure in Brink Air 70?
If there's a 4-way switch closure between terminals in your Brink Test Equipment, here's how to address it: First, remove the voltage from the appliance. Check the connection to the 4-way switch. If necessary, replace the 4-way switch. After that, put the voltage back on the appliance, and the fault should reset automatically.
What to do if 14-pole connector X5 is not connected on Brink Test Equipment?
To resolve the issue of a disconnected 14-pole connector X5 in your Brink Test Equipment: First, take the voltage from the appliance. Place the 14-pole connector on X5. Then, put the voltage back on the appliance. The fault should automatically reset.
General| Brand | Brink |
|---|---|
| Model | Air 70 |
| Category | Test Equipment |
| Language | English |
Details the components included in the heat recovery appliance package.
Provides technical specifications for the Air 70 appliance.
Illustrates the physical dimensions of the Air 70 appliance and extension kits.
Explains the basic functionality and features of the Air 70 appliance.
Defines the conditions under which the bypass function is activated.
Describes the frost protection mechanism for the heat exchanger.
Highlights the specific features and connectivity of the Air 70 Plus model.
Outlines general installation guidelines and compliance requirements.
Details how to mount the appliance, including pitch and clearance requirements.
Provides instructions on painting the front cover's outlet grille.
Details how to connect the appliance to the mains power supply.
Explains how to connect an optional 4-way switch for the Plus version.
Describes how to connect the eBus for communication between appliances.
Details the connection of an optional On/Off switch for permanent power.
Explains how to connect the MODBUS for building automation systems.
Describes how to connect/disconnect the appliance to/from the mains power.
Explains how to turn the appliance on and off using the push buttons.
Details how to adjust the air flow rate using the appliance's push buttons.
Explains how to reset the appliance to its default factory settings.
Refers to the Brink service tool for advanced installer settings.
Provides guidance on identifying and resolving common faults indicated by LED patterns.
Explains the user maintenance procedure for cleaning or replacing appliance filters.
Details the annual maintenance tasks for the heat exchanger and fans.
Illustrates the wiring connections for the basic control board.
Shows the wiring diagram for the optional Plus control board.
Details the procedure for installing the optional Plus printed circuit board.
Explains how to connect the humidity sensor to the Plus PCB.
Provides examples for connecting a multiple switch, including filter indication.
Shows wiring for a multiple switch with filter status indication.
Illustrates the connection of a wireless remote control system.
Details how to connect the CO2 sensor to the Plus PCB for air quality monitoring.
Explains how to connect an external switch for stopping the fan.
Describes the connection of the Brink home i module for smart home integration.
Explains how to connect the Air 70 to a MODBUS network for building automation.
Details how to link multiple Air 70 appliances together using the eBus connection.
Provides an exploded diagram of the appliance and a list of parts with article codes.
Lists adjustable settings and their ranges when using the Brink service tool.
