Step 9
Attach right side door bracket to
right front cart panel using two
M4 X 10mm bolts. The right side
door bracket is stamped with an 'R.'
Step 10
Attach left side door bracket to left
front cart panel using two
M4 X 10mm bolts. The left side
door bracket is stamped with an 'L.'
Step 11
Attach the two basket brackets to
the inside left front leg using four
M4 X 10mm bolts.
Step 12
Attach the basket guide onto the
left side door rear panel using two
M4 X 10mm bolts.
27
