32
Step 25
Insert grease tray into opening on
backside of grill. Make sure to slide
tray onto tracks as illustrated.
Step 26
Slide grease cup into grease cup
bracket located under grill bottom
on backside of grill.
Step 27
Hang stainless steel bucket in
cut-out of left side table/ice bucket
assembly.
Step 28
Place ice bucket insulation around
stainless steel bucket and secure
drain with two rubber gaskets and
brass retaining nut as illustrated.
Grease Tray
Stopper
Drain
Rubber Gasket
Stainless Steel
Ice Bucket
Side Table/Ice
Bucket Assembly
Ice Bucket
Insulation
Rubber Gasket
Retaining Nut
To Next Page
