Choose a good, cleared assembly
area and get a friend to help you put
your grill together. Lay cardboard
down to protect grill finish and
assembly area.
CAUTION: Some parts may
contain sharp edges.
Wear protective gloves
if necessary.
Step 1
Attach cart base to side cart legs.
Insert four M6 X 12mm bolts (black)
and star washers (black) through
cart base and into legs and tighten
securely.
Step 2
Attach front panel to legs using
four M6 X 12mm bolts (black) and star
washers (black).
Step 3
Attach tank block bar onto cart base
and front panel using two M6 X 12mm
bolts (black).
Step 4
Attach the rear support to the rear
legs of the cart frame assembly using
two M6 X 12mm bolts (black) and star
washers (black).
23
