Grill Body
Assembly
25
Note: With the help of a friend, turn
the cart to its upright position.
Try to minimize the stress to
the legs. Lock the casters to
stabilize the grill before
performing Step 9.
Note: When performing Step 9,
lift grill body from front and
rear panels to avoid injury to
hands and fingers.
Step 9
With the help of a friend, place grill
body assembly on grill cart. Grill
body will rest between upper side
sections of cart. Align bolt holes
located on the inside of the grill
body assembly. Secure using four
M6 X 12mm bolts (black) with star
washers (black).
To Next Page
