4 Screws
1 Motor Mount Bracket
4 Nuts
1 Spit Rod Support Bracket
PARTS LIST:
1 Motor
1 Left Hand Spit Rod
2 Forks
1 Right Hand Spit Rod
1 Wooden Handle
1
2
3
4
5
6
7
8
9
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY IN THIS
MANUAL AND THE GRILL MANUAL BEFORE ASSEMBLING OR OPERATING YOUR
ROTISSERIE AND GRILL.
The following tools are required to assemble this Brinkmann ProSeries
TM
Rotisserie:
• Phillips & Flathead Screwdrivers
• Adjustable Wrench
2
(Proof of purchase will be required.)
Inspect contents of the box to ensure all parts are included and undamaged.
3
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
2
4
5
1
7
6
8
9
6
8
To Next Page
