HARDWARE IDENTIFIER
Illustrations on this page
are to scale for faster
identication of hardware
during assembly.
Drawbar Pin: 1/2" x 2 1/2" (x1) . . . . . . . . . . . . . . . . . . . . . .
B-3861
50
Hairpin Cotter (x1)
D-146P . . . . . . . . . . . . . . . .
51
41
Nut: Hex Jam
1/2” (x4) . . . . . . . . . . . . .
31M1600P
Bolt: Hex Head,
5/16 x 3/4” (x3) . . . . . . . .
2M1012P
31
Bolt: Hex Head,
1/2” x 3 1/2” (x2) . . . . . . . . . . . . . . . . . .
B-6517
32
Bolt: Hex Head 5/16 x 3” (x4) . . . . . . . . . . . . . . . .
4M1048P
37
Bolt: Carriage 5/16 x 1-3/4” (x2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11M1028P
42
Washer: Lock
5/16” (x11) . . . . . . . . . . . .
44
40M1000P
Washer: Lock
1/2” (x2) . . . . . . . . . . . .
45
40M1600P
Washer: Flat
1/2” (x6) . . . . . . . . .
47
45M1717P
Washer: Flat
5/16” (x2) . . . . . . . . . . . .
45M1111P
46
Bolt: Hex Head 5/16 x 2” (x4) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2M1032P
34
40
Nut: Hex Head
5/16” -18 (x11) . . . . . . . . . . .
30M1000P
2
Nut: Hex Head Locking
5/16” -18 (x2) . . . . . . . . . . . .
B-1674P
English Manual
60
Nut: Nylon Lock
1/2” -30 (x2) . . . . . . . . . .
B-5096Y
