BRIO 612 - Page 11

x2
<54 (1371)
17. Fitting Cassettes for Double Screens
i. ii.
INSERT
B
B
CASSETTE
ASSEMBLY
RSC
CHANNEL
RSC
CHANNEL
A
ROTATE
PIVOT
A
A
RSJ
JAMB
MOUNTING
EXTRUSION
RSC
CHANNEL
meeting point*
TRACK
(RST or RSTT)
iii.
SLIDE TO
MEETING
POINT
RSC
CHANNEL
iv.
MEETING POINT
SLIDE SLIDE
CASSETTE
ASSEMBLY
CASSETTE
ASSEMBLY
ANCHOR BLOCKS
Refer to page 6 “Fitting Top Track Cassette”
INSTSCREEN | Rev | |3 C Feb 2020 11
18. Fitting Magnet and Magnet Plates for Double Screens
HANDLEBAR
WS-HDCEXP
HANDLEBAR
COVER
HANDLEBAR
WS-MST
MAGNETIC
STRIP
WS-MST
MAGNETIC
STRIP
A.
WS-MST
MAGNETIC
STRIP
WS-MST
MAGNETIC
STRIP
WS-MST
MAGNETIC
STRIP
i INSERT
ii CUT
FULL
LENGTH
B.
Center
Bottom
Top
x3
>54 (1371)
4 (101.6)
4 (101.6)
Top
4 (101.6)
4 (101.6)
Bottom
PRE-DRILL Ø1.5
(1/16in) HOLES
PRE-DRILL Ø1.5
(1/16in) HOLES
PRE-DRILL Ø1.5
[1/16] HOLES
WS-MP
MAGNET
PLATE
SC3GX7S
3G X 7 CSK
SCREW SS
WS-MP
MAGNET
PLATE
C.
WS-HDCEXP
HANDLEBAR
COVER
