BRISTERS CHUCK WAGON - Page 40

Reference
Number
Part
Number
Part Description - 2WD Models
Quantity
Required
80 18312 Roof, green 1
18301 Roof, Red 1
18351 Roof, Camo 1
18391 Roof, Top Vinyl Trim 1
18390 Roof, Hardware bolt kit
50847 Clamp-Tube-vinyl coated 1-3/4" 4
50087 bolt, 1/4" x 1 4
50718 Washer, ¼” rubber domed 4
50001 nut, 1/4" nylock 4
85 18400 Windshield - clear
18401 Windshield - tinted
18403 astener kit, windshield F
88 40723 Front receiver hitch kit
101 20010 Engine, Honda 11hp 1
- 50202 3/8-16 x 1 3/4" Hex Hd Bolt 4
- 50740 3/8" Flat washer, USS 4
102 20833 ana Transaxle D 1
70057 Neutral Safety Switch 1
51500 Shims – Neutral Safety Switch
103 45423 Swing arm, CW - Black 1
104 45430 Motor Plate, CW - Black 1
105 18023 Throttle Guard Laser 1
- 50086 1/4-20 x 1 1/4" Hex Hd Bolt 3
- 50082 1/4-20 x 2 1/4" Hex Hd Bolt 1
- 50000 /4" Keps Nut 1 5
- 50715 1/4" Flatwasher, USS 8
107 20648 TC, Driver Comet 500 – used before Serial Number # 25658 1
20665 TC, Driver CVTECH – used fter Serial Number # 25658 1 a
108 20649 TC, Driven Comet 500 – us efore Serial Number # 25658 1 ed b
20666 TC, Driven CVTECH – used fter Serial Number # 25658 1 a
109 11166 Brake Shoes - Rear UTV – Dana 2
110 50745 1" I.D. Spacer Washer – Comet only (not used with CVTech pulley) 4
111 - 1/4" Key stock 1
112 - 3/8" I.D. Fender Washer – Comet only (not used with CVTech pulley) 1
113 50741 3/8" Lock Washer – Comet only (not used with CVTech pulley) 1
114 50219 3/8x 3" Bolt Hex Hd NF – Comet only (not used with CVTech pulley) 1
115 20693 Belt, Comet 300668 - used before Serial Number # 25658 1
20694 Belt, CV TECH – used after Serial Number # 25658 1
116 50239 1/2 x 2" SAE 1
40
