Reference
Num er N
Part Description – 265cc 2WD Models
Qu
Required b
Part
umber
antity
1 45419 Frame, CW11 1
2 45401 Rear frame stub, CW - black 2
50168 5/16 x 2-1/4" USS Socket Head bolt 2
50007 nut, 5/16 nylock 2
50702 bent washer 5/16 2
3 45413 bumper, CW - black 1
45432 Bumper, Trail Wagon – Black 1
50167 bolt, 5/16 x 2 4
50007 nut, 5/16 nylock 4
50702 bent washer 5/16 4
70208 Vinyl Caps 1 3/4 x 1 1/2 2
4a f, CW265 – black 45412 Brush Guard roo 1
4b TW265 – black 42300 Brush Guard roof,
50168 5/16 x 2-1/4” USS Socket Head bolt 4
50007 nut, 5/16 nylock 4
50702 bent washer 5/16 4
5 45411 brshgrd seat back, CW – black 1
50168 5/16 x 2-1/4” USS Socket Head bolt 2
50007 nut, 5/16 nylock 2
50702 bent washer 5/16 2
6 42045 A-arm upper, 265 – black (left or right) 2
51100 suspension bushings 4 ea
50262 bolt, 5/8 x 9” 1 ea
50254 Bolt, 5/8 x 3.5 bolt 1 ea
50015 Nut, 5/8 nylock 2 ea
7 42046 A-arm Lower, 265 – black (left or right) 2
51100 suspension bushings 4 ea
50262 bolt, 5/8 x 9” 1 ea
50254 Bolt, 5/8 x 3.5 bolt 1 ea
50015 Nut, 5/8 nylock 2 ea
8 45408 pindle mount, CW – black s 2
9a 45406 Spindle, left – black 1
9b 45407 Spindle, right – black 1
51100 suspension bushings 2 ea
50262 bolt, 5/8 x 9” 1 ea
50015 Nut, 5/8 nylock 1 ea
10 30604 Hub, 4 bolt high speed 1” Complete with Bearings & Seals 2
11205 bearing, 1” tapered
30620 seal
47
