15
STROLLER ASSEMBLY
INSTALLING THE REAR WHEELS
A Hold in the release button in the
centre of the wheel and slide the
mounting pin into the housing on the
rear axle.
B Pull on both rear wheels to ensure
they are locked into the frame
housings.
PLEASE NOTE: The mud guards are marked ‘L’ (LEFT) and ‘R’ (RIGHT) for
correct fitting.
A Slide the mud guard onto the
mounting bracket above each rear
wheel housing and push down until it
locks into place.
INSTALLING THE MUD GUARDS
