Harness to Booster Mode: Removing the Harness and Buckle
1 Loosen the harness
completely.
a Press release lever
b Pull both harness straps forward
4 Open the CLICKTIGHT.
* Locate the two slots in the
CLICKTIGHT cover.
* Squeeze the CLICKTIGHT
release levers.
5 Unhook the harness straps
from the CLICKTIGHT hip
anchors.
2 Unhook the harness straps from
the yoke.
* Store the yoke in a secure
place in the base.
3 Pull the harness straps out of
the slots.
7 Turn and pull the buckle
retainer through the slot in the
child seat shell.
6 Unhook the retaining clips at
the back of the seat cover. Pull
the seat cover forward and
over the belly pad.
8 Fasten the harness buckle.
7 Fasten the chest clip.
* Push together until a click is
heard.
9 Pull the adjuster strap to
tighten the harness.
* Pull the harness adjuster away
from the child seat (parallel to
the ground) to tighten.
Switching Between Modes Switching Between Modes
