17
HOW TO SET-UP
1. Outer crotch strap slot
2. Inner crotch strap slot
3. Lap strap slot
4. Harness tongues & buckle
5. Shoulder harness strap
6. Lower shoulder strap slots
7. Medium shoulder strap slots
8. Upper shoulder strap slots
9. Maximum shoulder height marker.
10. Harness Adjuster (under cover ap)
1
2
3
3
4
6
5
5
8
7
8
7
6
5
5
4
3
3
2
1
9
10
F. The Infant Carrier is tted with three shoulder strap positions.
As the baby grows, the shoulder straps must be moved to higher slots.
The shoulder straps must be in the slots which are
nearest to the child’s shoulders, but not lower than
the child’s shoulders.
If the baby is newborn you will need to use either slot 6 or 7 and crotch strap
position 2. With the baby in the carrier, check that the slot is just above the baby’s
shoulder. If the strap is not in that slot then change the slot as described on pages 18
to 20. If the slot is just above the shoulders then go to page 21.
