58
ALTERNATIVE INSTALLATION IF SEATBELT LOOSENS
LAP-SASH SEAT BELT
If a seat belt will not stay tight, then a
Gated 3-Bar Slide may be used to prevent
loosening.
There may be two types of Gated Slides
available, Curved and Flat.
Before installing the restraint, join the
lap-sash seat belt by using the Gated 3-Bar
Slide stored under the carrier.
Hollow side
Inner
strap
A. Hold the lap and sash straps together and fold
as shown. Slide the inner strap into the Gated
3-Bar Slide followed by the outer strap.
B. The two straps should slide freely in the Gated
3-Bar Slide slot.
Faces
towards
restraint
C. Repeat previous step A for the other
slot in the Gated 3-Bar Slide.
Ensure the Lap portion of seat
belt is nearest to the restraint
Curved
Flat
