51
Push in under handle
B. Align the Adaptor in the recess under the
handle boss, push up and click into place.
A. To attach the Britax Stroller Click & Go™ Adaptor to the Infant Carrier ensure the
Carrier's Handle is in “Rocking position” , disconnect the elastic under the
handle boss and pull the trim away from the side of the carrier and trim is placed
aside to align the holes.
B
TRAVEL SYSTEM -
BRITAX STROLLER CLICK & GO™ADAPTOR
2
Push in Locking Pin
C
C. Insert Locking Pin into hole. Align both top
and bottom holes.
2
* Refer to page 13 for handle position
