Extension Strap distance to be measured.
Length 300mm (Use Safe-n-Sound part 0035 or equivalent).
Length 600mm (Use Safe-n-Sound part 0036 or equivalent).
Available from all major child restraint retailers.
DISTANCE TO MEASURE TO
THE ANCHOR POINT
The shaded areas of this diagram illustrate the possible locations of the anchor
tting. Within each shaded area is an anchor tting showing the correct way to install
the tting. Ensure the anchor tting is aligned as illustrated unless stated otherwise in
the vehicle owner’s handbook.
Adjustable upper
Anchorage strap.
FRONT OF VEHICLE
INSTALLATION OF CAR ANCHOR FITTING
