Britec ELEGANCE BA26 - Window Slider Kit Installation

48
www.britec.es
Window width
min. 67,5 cm
max. 123 cm
Window height
min. 67,5 cm
max. 123 cm
Fig. 5
Fig. 5a
b) Window Slider Kit Installation
The installation manner of window slider kit is mostly in “horizontal” and “vertical”. As shown
Fig.5 and Fig.5a, check the min. and max. size of the window before the installation.
1. Install the window kit on the window (Fig.5, Fig.5a);
2. Adjust the length of the window slider kit according to the window width or height, and
fix it with the dowel;
3. Insert the Window Connector hose to the hole of the Window Kit.
