Cooler Operation (cont.)
Water Inlet Solenoid Operation (cont.)
If power present and inlet solenoid doesn't open:
• Check the water inlet solenoid wire loom and connections.
Isolate power and check the Water Inlet Solenoid coil resistance (4.1 kOhms).
INLET VALVE - NEUTRAL
INLET VALVE - ACTIVE
OFF
10 A
V
COM
1000V- - -
750V
V
kOHMS
Multimeter
FUSED
3.9
• Check if the water inlet solenoid is blocked.
Replace water inlet solenoid.
