BRKT ARM3780HD - Hardware Product Numbers; Product Component Parts

P 3
HARDWARE PRODUCT NUMBERS
PRODUCT COMPONENT PARTS
A
Minimum: 200mm x 100mm
Maximum: 700mm x 500mm
Flat Panel Mounting Pattern (W x H)
9
5mm
SPACER
X 4
14
8
SQUARE
WASHER
X 4
WALL
ANCHOR
X 6
5
4
2
1
M6 x 15
X 4
M8 x 15
X 4
M6 x 30
X 4
M8 x 30
X 4
3
6
M4 x 12
X 4
M4 x 30
X 4
10mm
SPACER
X 4
10
13
STEEL
WASHER
X 8
11
12
LAG BOLT
8mm x 65mm
X6
LAG BOLT
STEEL WASHER
X6
ALLEN
WRENCH
X 1
M6
WASHER
X 2
M6
NYLON
NUT
X 2
A3
A2
A1
M8 x 45
X 4
7
700(MAX)
500(MAX)
Before Installing: Check the VESA pattern of the TV back
B
Product Components
Contents Qty
Description
A 1 Wall Bracket
B 1 Universal Monitor Bracket
