Broan 112 - Service Parts; Parts List; Exploded View Diagram

MODEL 112
Page 6
SERVICE PARTS
99045133B
KEY PART
NO. NUMBER PART DESCRIPTION
1 99522899 Cover (White)
2 99522400 Cycling Thermal Overload Limit Switch
3 99521763 Thermal Fuse
4 99521765 Motor
5 99020130 Blower Wheel
6 99521760 Motor Plate
7 99521761 Element Retainer
8 99271288 Heater Element (2 Required)
9 99521767 Thermostat (Optional)
10 ‑‑‑ Housing (White)
11 99521769 Knob (Optional)
12 * Screw, 6‑20 x 1/4 Slotted Hex Head
(2 Required)
13 * Screw, 6‑20 x 3/8 Slotted Head
Head AB Pt.
14 * Nut, 6‑32 Hex Keps (2 Required)
15 * Screw, 10‑16 x 3/8 Slotted Head
Head AB Pt.
16 * Nut, 10‑32 Hex Keps (2 Required)
17 * Screw, 10‑32 x 1/2 Slotted Head
Head Type F
18 * Screw, 6‑32 x 3/4 Phillips Pan Head
(2 Required) (Optional)
19 * Screw, 8‑18 x 1/4 Slotted Pan Head
(4 Required)
20 99522782 Alarm Light
* Standard Hardware. May be purchased locally.
SERVICE PARTS
