Operator´s manual

SCANDIA

version 1-2020-01-01

Table of Contents

Questions and Answers

K
Kevin JohnsonAug 7, 2025
Why does the diesel engine stop in my BRODDSON Farm Equipment?
- S
  susan77Aug 7, 2025
  If the BRODDSON Farm Equipment's diesel engine stops, there might be several reasons. You may have no fuel in the fuel tank, so you should fill it. Another cause can be a clogged fuel filter, which requires changing the fuel filter. Also, the engine temperature might be too high, so fill water in the cooler mixed with anti-freezer fluid if needed. Finally, low oil pressure could be the problem, in that case add oil to the diesel engine.
C
Courtney BridgesAug 12, 2025
What to do if there is no water from the sprinkler system in my BRODDSON Farm Equipment?
- A
  andrewsstevenAug 12, 2025
  If no water comes from the sprinkler system of your BRODDSON Farm Equipment, it could be due to several reasons. First, check if the water spray nozzles are clogged and clean them if necessary. Also, check if the water tanks are empty and refill them. A clogged water filter could also be the culprit, so clean the filter insert. Lastly, the water pump might have failed, so check the pump and refurbish if needed.
M
Martha HayesAug 18, 2025
What to do if the sweeping operation does not start on my BRODDSON Farm Equipment?
- K
  Kimberly RobertsAug 18, 2025
  If the sweeping operation does not start in your BRODDSON Farm Equipment, the hydraulic oil might be too cold; let the oil warm up by running the diesel engine for a few minutes. The elevator could also be blocked by a foreign object; run the elevator and main brush in reverse. Check if the hydraulic oil level is too low and fill it if needed. There might be an electrical error, consult the electrical scheme. Also, check if the wash button is activated and deactivate it.
A
Amy MartinAug 25, 2025
How to prevent my BRODDSON Farm Equipment sweeper from leaving stripes?
- L
  Leah WashingtonAug 25, 2025
  If your BRODDSON Farm Equipment sweeper leaves stripes, reduce the sweeping width. You may also need to mount new parts, adjust the collector shoe, mount a new elevator rubber, change the infeed rubber or adjust its height, or replace the bushings in the collector shoe arm.
G
Guy FloresAug 30, 2025
Why does the side brush on my BRODDSON Farm Equipment throw sand back against the curb stone?
- J
  James GouldAug 30, 2025
  If the side brush of your BRODDSON Farm Equipment throws back sand against the curb stone, the tilting angle might be too small. To fix this, increase the tilting angle.

Summary

INTRODUCTION

Before operation

Read operating instructions, check safety equipment and machine function.

During operation

Ensure no one is close to or riding on the machine.

Driving in strong slopes

Adjust speed for maneuverability and control, avoid 'tied together' situation.

Emergency Stop

Stop engine and functions immediately via remote control or emergency stop button.

MAINTENANCE OVERVIEW

WARRANTY

MAIN DIMENSIONS FRONT AND REAR VIEW

MAIN DIMENSIONS SIDE VIEW

REQUIREMENTS ON THE TRAILER VEHICLE

RECOGNITION OF SIGNS AND SIGNALS

General Warning Instructions

Serious personal or property damage can occur if instructions are not followed.

Specific Warning Labels

Notes on electrical box sticker and right side cover sticker.

ANTIFREEZE SYSTEM

To prevent freezing (below 0°)

Steps to prevent freezing, including emptying tanks and running flushing fluid.

CONNECTING THE TOWING VEHICLE

DISCONNECTION OF THE SWEEPER

MANUAL LOWERING OF THE SWEEPING DEVICE

Lowering the Sweeping Unit

How to manually lower the sweeping unit when the engine is not running.

Maintenance Position Bypass

Position B for maintenance of hydraulic hoses, bypasses return line.

LIFT OFF THE SWEEPER

Lifting the Sweeper

Attach lifting cables to elevator sides and rear. Markings available.

Anchoring for Transport

Fix machine on each side of the shaft in mounting loops for transport.

THE LOADS OF THE TRUCK

FIRST HOURS OF OPERATION

REMOTE CONTROL BOX

MAIN OPERATIONAL BOX

MANUAL CONTROL OF HYDRAULIC VALVES

SWEEPING

SPRINKLER SYSTEM

HYDRAULIC OIL

GENERAL REGULATIONS

Service Notes and Safety

Check for oil leaks, worn parts, and safety during elevator operation.

Hydraulic Hose Replacement

Steps for replacing hydraulic hoses, including valve operation and safety precautions.

Checking Oil Level

How to check hydraulic oil level using the level glass and filling port.

DAILY WASH

8 HOUR SERVICE

40 - HOUR SERVICE

Water Filter and Spray Nozzles Maintenance

Cleaning filter insert, disassembling nozzles, checking water level, and tire pressure.

Diesel Engine and Elevator Rakes Maintenance

Replacing oil/fuel filters, changing oil, and re-tightening elevator rake nuts.

100 - HOUR SERVICE

250 - HOUR SERVICE

500 - HOUR SERVICE

2 - YEARS SERVICE

REPLACEMENT OF SIDE BRUSHES

REPLACEMENT OF MAIN BRUSH

BRUSH PRESSURE ADJUSTMENT

Main Brush Horizontal Level Adjustment

Adjusting the horizontal level of the main brush by changing the lifting chain link.

Side Brushes Surface Pressure Adjustment

Adjusting surface pressure for side brushes, with instructions for system reset.

ANGLE ADJUSTMENT OF SIDE BRUSHES

DAMAGE PROTECTION SPRING FOR SIDE BRUSHES

Adjustment of Sweeping Width

Adjusting the sweeping width using the adjustment nut on side brushes.

ADJUSTMENT OF ELEVATOR BELTS

ADJUSTMENT OF CONVEYOR RUBBER BELT

ADJUSTMENT OF COLLECTOR SHOES & STRING COLLECTOR

Adjustment of Collector Shoes

Adjusting collector shoes by moving the adjustment on the elevator upwards or downwards.

Adjustment of String Collector Rubber

Adjusting string collector rubber by moving chain links to ensure it doesn't touch the ground.

PIVOT BRAKE ADJUSTMENT ON FRONT WHEEL (REFERS TO 3-WHEEL)

WINTER STORAGE

RE-START OF THE UNIT

TROUBLESHOOTING

TECHNICAL DATA

BRODDSON SCANDIA Specifications

General

Brand	BRODDSON
Model	SCANDIA
Category	Farm Equipment
Language	English
