TECHNICAL DATA – OSR45
Lifting capacity
(According to EN13001 HC2, HD1, U6, Q3
(600,000 cycles)
51 metric tons evenly loaded
51 metric tons ± 10% eccentric loaded
Tare weight
Overheight frame 1.80 m: About 2.30 metric tons
Overheight frame 2.25 m: About 2.42 metric tons
Overheight frame 2.50 m: About 2.50 metric tons
Overheight frame 2.70 m: About 2.55 metric tons
Storage fixture: 1.55 metric tons
Dimensions
Refer to dimensional drawing
Overheight capacity
Refer to dimensional drawing
Connection to spreader
Twistlock (with cargo)
Latches (without cargo)
Standard colour
RAL2004 (pure orange)
Latch & gather in RAL1003 (signal yellow)
Overheight brace coating hot dip galvanized
Surface conditioning
Sand-blasted SA 2.5
50- 90 μm 2-component zinc epoxy
100 μm 2-component MIO pigmented
70 μm Polyurethane
Design criteria
EN13001; DIN 15018 H
2
B
3
; FEM 1.001; British Standard BS 2573
Manuals
Full service and repair manual supplied in English
Warranty
1 year
This specication is subject to alterations without prior notice.
