8. REAR WHEEL
To complete the unfold, hold the handlebar with your left hand and with your right hand lift the bike by the saddle to
swing the rear wheel backwards (fig. 7) into position.
Put the bike down and apply downward pressure to lock the rear frame (fig. 8) in place. There should be a click to
indicate that the frame is locked.
10. PRE-RIDE CHECKS
• Make sure the hinges are closed properly
• Make sure the tyres are inflated (100psi)
• Make sure the brakes function properly
Fig. 7
Fig. 8
Fig. 1
9. FITTING THE BELL
The bell should be fitted to the handlebar on the oposite side to the gear shifter
(fig. 1), on the bend of the bar adjacent to the brake lever. TIghten the fixing
screw using a cross-head screwdriver. Do not overtighten the screw.
WARNING
Ensure the bell does not restrict the control cables or handlebar movement when riding.
The bell should not contact the fork & front wheel or obstruct the control cables when
folding/unfolding the bike.
SHIFTER
BELL
