a part of the building, say the front wall of the building and then installing all
mounting plates in the same orientation with respect to this (see figure 6).
Front Wall Front
Wall
Orientate
all
mounting
plates
in the
same
direction
Figure 6
Mounting Plate Mounting Plate
Large
hole
nearest
front
wall
Mounting Plate Mounting Plate
Connect the battery to the battery snaps as shown in the Quick Start Guide (for
9V Replaceable Battery models only).
7. Carefully line up the unit on the base, gentle press home & twist on. (This
connects the batteries in the 10 Year Lithium Battery models).
Install all the other Alarms similarly.
14
