Brooks EIB605 - Quick Start Guide; Siting and Battery Connection

ALARM
1. Quick Start Guide
LOCATE CORRECT SITING POINT FIX BASEPLATE TO CEILIN G
ALARM SHOULD BE CEILING MOUNTED AT LEAST 300MM FROM
WALLS & OBSTRUCTIONS, IDEALLY CENTRALLY IN ROOM/AREA
CONNECT BATTERY SNAPS 9V REPLACEABLE BATTERY MODELS ONLY
9 VO LT
BATTERY
BATTERY
CONNECTORS
CONNECT THE BATTERY TO THE
BATTERY SNAPS TO POWER THE UNIT
BASE OF
ALARM
4
B17078-R0-Ei600 SERIE-BROOKS.indd 4
ON 10 YEAR LITHIUM BATTERY
