EF4-N11, V41A, N21, V51A, MA4-N31, V61A 28/31
2001.9
Gauge parts list
[Models MA4-N31, V61A]
Ruffling w/ piping Taping
Application
5 Threads 4 Threads 5 Threads 4 Threads 5 Threads 4 Threads
Sub-class
S=Standard
H=High-lift
E=Extra high-lift
75
−5 S
76
−5 S
77
−5 S
−6 H
78
−5 S
81
−4 S
−5 S
82
−5 S
(mm)
Needle gauge
253
1. Needle (Q’ty)
151474−014 (2)
S25550−001
(S25553-001)
S25555−001
(S25553-001)
S19330−201
(S30971-001)
2. Presser foot assy
(Presser foot .F)
S20404−001 S20406−001 S20404−001
3.
Needle clamp assy
S19182−001 (5)
S19183−001 (5)
S19184−001 (6)
S20235−001 (4)
S20236−001 (5)
4. Needle plate
5.
Main feed dog assy
(Main Feed dog)
(Chain feed dog)
S19224−201
(S19225-201)
(S33172−001)
L
S19226−101 (5)
(S19227-101)
(S19223-101)
F
S19224−101 (6)
(S19225-201)
(S33172-001)
L
S20241−101
(S20242-101)
(S20243-101)
H
S19246−001 S20245−001
6.
Differential feed dog
144074−350
7. Upper knife
8. Lower knife
S20582−001
T = 1.5
9. Over looper
S20424−001
B
S20423−001
M
S20424−001 (5)
B
S20428−001 (6)
C
S20423−001
M
S20424−001
B
S20423−001
M
