EF4-N11, V41A, N21, V51A, MA4-N31, V61A 29/31
2001.9
Gauge parts list
[Models MA4-N31, V61A]
Taping Extra heavy Binding
Application
5 Threads 4 Threads 5 Threads 4 Threads 5 Threads 4 Threads
Sub-class
S=Standard
H=High-lift
E=Extra high-lift
83
−4 S
−5 S
−6 H
84
−4 S
−5 S
−6 H
85
−3 E
−5 E
86
−5 E
89
−4 S
−5 S
90
−4 S
−5 S
(mm)
Needle gauge
533
1. Needle (Q’ty)
151474−016 (2) 151474−018 (2) 151474−014 (2)
S20882−201
(S30971-001)
S25557−001
(S19340-001)
S25560−101
(S19312-001)
2. Presser foot assy
(Presser foot .F)
S20406−001 S29631−001 S20404−001
3.
Needle clamp assy
4. Needle plate
S20231−001 (4)
S20233−001 (6)
S20232−001 (5)
S25200−001 (3)
S25201−001 (5)
S25202−001 (4)
S25203−001 (5)
5.
Main feed dog assy
(Main Feed dog)
(Chain feed dog)
S20239−101
(S20240-101)
(S19232-101)
F
S19228−101
(S19229-001)
(S19223-101)
F
S19221−201
(S19222-201)
(S33172-001)
L
S20244−001 S25566−001 S19245−001
6.
Differential feed dog
Upper knife
144074−350
Angle knife
S20898−101
Upper knife
144074−350
7. Upper knife
Angle knife
8. Lower knife
S20582−001
T = 1.5
S20583−001
T = 1.5
S20582−001
T = 1.5
9. Over looper
S20424−001
(4,5) B
S20428−001
(6) C
S20423−001
(4,5) M
S20421−001
(6) L
S20438−001
G
S20429−001
Q
S20424−001
B
S20423−001
M
