Brother HL-L2375DW

To Next Page

To Previous Page

2-4

Confidential

 Cleaning

Use a soft dry lint-free cloth.

Warning

DO NOT use any flammable spray or flammable solvent such as alcohol, benzine,

or thinner to clean the machine. DO NOT use these articles near the machine.
