Brother HL-L5200DW Service Manual

2-17
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
8E01 ― 9204
When printing from the paper tray 3,
paper type setting in the machine
does not match the setting in the
driver.
2-77
8E02 ― 9205
When printing from the paper tray 4,
paper type setting in the machine
does not match the setting in the
driver.
2-77
8F01 ― 9206
When printing from the paper tray 5,
paper type setting in the machine
does not match the setting in the
driver.
2-77
8F02 ― 9301
When printing from the MP tray, the
MP paper empty sensor detected that
there was no paper set in the MP tray.
2-78
8F03 ― 9302
When printing from paper tray 1, the
T1 paper empty sensor or the T1
paper feed sensor detected that there
was no paper set in paper tray 1.
2-78
9001
When printing from the MP tray, the
size of paper set in the MP tray does
not match the size specified by the
driver.
2-76 9303
When printing from paper tray 2, the
T2(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 2.
2-78
9002
When printing from the paper tray 1,
the size of paper set in the paper tray
1 does not match the size specified by
the driver.
2-76 9304
When printing from paper tray 3, the
T3(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 3.
2-78
9003
When printing from the paper tray 2,
the size of paper set in the paper tray
2 does not match the size specified by
the driver.
2-76 9305
When printing from paper tray 4, the
T4(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 4.
2-78
9004
When printing from the paper tray 3,
the size of paper set in the paper tray
3 does not match the size specified by
the driver.
2-76 9306
When printing from paper tray 5, the
T5TT paper empty sensor detected
that there was no paper set in paper
tray 5.
2-78
9005
When printing from the paper tray 4,
the size of paper set in the paper tray
4 does not match the size specified by
the driver.
2-76 9309
Detected that there was no paper set
in all trays when TrayAuto was
selected for printing.
2-79
9006
When printing from the paper tray 5,
the size of paper set in the paper tray
5 does not match the size specified by
the driver.
2-76
930A ―
9102 ― 9400
Firmware version of the main PCB is
older than that of the TT, MX and LT.
2-79
9103 ― 9501 ―
9104 ― 9502 ―
9105 ― 9503 ―
9200 ― 9504 ―
9201
When printing from the MP tray, paper
type setting in the machine does not
match the setting in the driver.
2-77 9505 ―
9202
When printing from the paper tray 1,
paper type setting in the machine
does not match the setting in the
driver.
2-77
9601 ―
9203
When printing from the paper tray 2,
paper type setting in the machine
does not match the setting in the
driver.
2-77
9608 ―

Brother HL-L5200DW Specifications

General

Color	No
N-up printing	2, 4, 6, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter XL24E, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	50 dB
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	450 mm
Package width	485 mm
Package height	377 mm
Package weight	13000 g
Display	LCD
Product color	Black, Grey
Display number of lines	1 lines
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-AES, WPA-TKIP
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/ v3, ICMP, Web Services (Print), CIFS client, SNTP client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input frequency	50 - 60 Hz
Power consumption (off)	6.5 W
Power consumption (standby)	32 W
Power consumption (printing)	640 W
Energy Star Typical Electricity Consumption (TEC)	1.763 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	255 mm
