Brother HL-L5200DW Service Manual

2-56
Confidential
 Error code 7100
The eject sensor remains ON (paper pass detected) even after the registration rear sensor
detected the end of paper pass.
 Error code 7200
When feeding from the MP tray, the registration rear sensor does not detect paper pass
within the specified time after the registration front sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Check if the back cover is open during duplex printing.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2
Eject actuator caught in some
sections of the machine
Reattach the eject actuator.
3 Fuser cover attachment failure Reattach the fuser cover.
4 Eject sensor failure Replace the eject sensor PCB ASSY.
5
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
6 Fuser cover failure Replace the fuser cover.
7
Damaged eject roller 1 drive
gears
Replace the main frame L ASSY.
8 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Remove the jammed paper.
• Add the paper properly using the MP tray paper guide.
• Close the front cover correctly.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
Registration rear actuator
coming off or caught in some
sections of the machine
Reattach the registration rear actuator.
3
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
4
Connection failure of the
registration clutch harness
Reconnect the registration clutch harness.
5
MP feed frame attachment
failure
Reattach the MP feed frame.
6
Registration rear sensor failure Replace the registration front/rear sensor PCB
ASSY.
7 Registration clutch failure Replace the registration clutch.
8
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
9
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
10 Main PCB failure Replace the main PCB ASSY.
