13 Left side of the TT

Harness colors are subject to change for some reason.

LT/TT connector

harness (WH)

T2TT relay harness (WH)

Low-voltage power supply

harness (WH, BR)

T3TT relay harness (WH)

Clamp

T4TT relay harness (WH)

T5TT relay harness (WH)

To in

12. TT control PCB ASSY

Clamp

T2TT unit

T3TT unit

T4TT unit

T5TT unit

TT balance sensor R

relay harness (WH)

Fan motor relay

harness (WH, BK, RD)

To in

12. TT control PCB ASSY

Default Chapter4
