2-8
Confidential
2.4 Block Diagram
Fig. 2-4
Main PCB
Eject stack sensor
Touch panel models only
External temperature/humidity sensor
Internal temperature sensor
Eject motor
Paper feed motor
T1: Models with 520-sheet only
Erase lamp PCB
Back cover/duplex
tray sensor
Develop release clutch
MP solenoid
T1 pickup clutch
Registration clutch
Front cover sensor
Relay front PCB
New toner
sensor
Toner amount
detection sensor
PCB (light reception)
Laser unit
LD PCB
BD sensor Polygon motor
Toner amount
detection sensor
PCB (light emission)
LT
LT control PCB
LT release clutch
LT pickup clutch
LT paper empty
sensor PCB
LT paper feed
sensor PCB
High-voltage
power supply PCB
Registration front/
rear sensor PCB
MP paper empty
sensor PCB
T1 paper feed
sensor PCB
TT
control
PCB
MX
MX 1bin switching solenoid
MX jam upper sensor
MX jam lower sensor
MX 2bin detection sensor
MX 4bin detection sensor
MX motor
MX 2bin switching solenoid
MX 3bin switching solenoid
MX switching solenoid
MX
control
PCB
MX
relay
PCB
MX 1bin stack sensor PCB
MX 2bin stack sensor PCB
MX 3bin stack sensor PCB
MX 4bin stack sensor PCB
MX back cover sensor
Wireless LAN PCBWLAN models only
Paper empty sensor PCB
Models with 520-sheet T1 and HL-5580D/5585D only
Center thermistor
Side thermistor
Heater
Low-voltage
power supply PCB
Eject sensor PCB
Fuser unit
Panel PCB
Touch panel models only
NFC models only
Panel PCB
Non touch panel
models only
LCD
Color LCD
NFC
LCD panel ASSY
LCD relay PCB
Key PCB
TT
T2TT
relay
PCB
T3TT
relay
PCB
T4TT
relay
PCB
T5TT
relay
PCB
T2TT pickup clutch
T2TT jam sensor PCB
T2TT paper feed sensor PCB
T2TT paper empty sensor PCB
T3TT pickup clutch
T3TT release clutch
T3TT jam sensor PCB
T3TT paper feed sensor PCB
T3TT paper empty sensor PCB
T4TT pickup clutch
T4TT release clutch
T4TT jam sensor PCB
T4TT paper feed sensor PCB
T4TT paper empty sensor PCB
T5TT pickup clutch
T5TT release clutch
T5TT jam sensor PCB
TT motor
TT balance sensor L
TT fan
Low-voltage Power Supply PCB
Relay connector
TT balance sensor R
Relay connector
T5TT paper feed sensor PCB
T5TT paper empty sensor PCB
Fuser fan
Models with 520-sheet only
