Brother HL-L6250DN Technical Reference Guide

CHAPTER 2 PCL - 54
Symbol map (Array of UI )
The symbol map, which has a list of symbol index numbers, is used to define the symbols for the symbol set.
This map defines the combinations of symbol index numbers and character codes.
5.2.4. Symbol set control command
Esc*c#S (27)(42)(99)#(83) <1Bh><2Ah><63h>#<53h>
 Values for # can be 0, 1, 2, 4, or 5.
 0 specifies to delete all temporary and permanent user-defined symbol sets.
 1 specifies to delete all temporary user-defined symbol sets.
 2 specifies to delete current user-defined symbol set.
 4 specifies to make current user-defined symbol set temporary.
 5 specifies to make current user-defined symbol set permanent.
5.2.5. Selecting the symbol set
Esc(symbol set ID (27)(40) <1Bh><28h>
 This command selects the symbol set (character set) for the primary font.
 Symbol set IDs consist of a number followed by a letter.
 Default symbol set ID is Roman-8. If an invalid default symbol set ID is selected, the symbol set becomes
Roman-8.
 The selectable symbol set varies depending on the printer model.
Symbol set Set primary font Symbol set Set primary font
ISO 60 : Norwegian 1 Esc(0D ISO 57 : Chinese Esc(2K
ISO 61 : Norwegian 2 Esc(1D ISO8859-1 (ECMA-94) Latin
1
Esc(0N
ISO 4 : United Kingdom Esc(1E Wingdings Esc(579L
Windows 3.1 Latin 2 Esc(9E PS Math Esc(5M
ISO 25 : French Esc(0F Ventura Math Esc(6M
ISO 69 : French Esc(1F Math-8 Esc(8M
HP German Esc(0G Symbol Esc(19M
ISO 21 : German Esc(1G ISO 8859-2 Latin 2 Esc(2N
ISO 15 : Italian Esc(0I ISO 8859-9 Latin 5 Esc(5N
Microsoft Publishing Esc(6J ISO 11: Swedish; names Esc(0S
Desk Top Esc(7J PS Text Esc(10J
HP Spanish Esc(1S Ventura International Esc(13J
ISO 17 : Spanish Esc(2S Ventura US Esc(14J
ISO 10 : Swedish Esc(3S ISO 16 : Portuguese Esc(4S
ISO 14 : JIS ASCII Esc(0K ISO 84 : Portuguese Esc(5S
ISO 85 : Spanish Esc(6S Windows 3.1 Latin 5 Esc(5T
PC Turkish Esc(9T ISO 6 : ASCII Esc(0U
Legal Esc(1U ISO 2 : IRV Esc(2U
Roman 8 Esc(8U Windows 3.0 Latin 1 Esc(9U
PC-8 Esc(10U PC-8 D/N Esc(11U
PC-850 Esc(12U Pi Font Esc(15U
PC-852 Esc(17U Windows 3.1 Latin 1 Esc (19U
MC Text Esc(12J ISO 8859-10 Latin 6 Esc (6N
OCR-A Esc(0O OCR-B Esc(1O

Brother HL-L6250DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	46 ppm
Processor model	Cortex-A9
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	50 dB
Display	LCD
Product color	Gray
Display number of lines	16 lines
Printing colors	Black
Recommended duty cycle	0 - 5000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter XL24E, PCL 6, PDF 1.7
Cables included	AC
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	450 mm
Package width	485 mm
Package height	531 mm
Package weight	15000 g
Power consumption (off)	0.04 W
Power consumption (standby)	32 W
Power consumption (printing)	740 W
Power consumption (PowerSave)	390 W
Energy Star Typical Electricity Consumption (TEC)	2.162 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Paper tray media types	Envelopes, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Security algorithms	EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SNMP, SSL/TLS
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service, Windows RT
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS resolver, mDNS, LLMNR responder, LPR/ LPD, custom Raw Port/Port9100, IPP/IPPS, FTP server, TELNET server, HTTP/HTTPS server, TFTP client en server, SMTP client, SNMPv1/v2c/ v3, ICMP, web services (printen), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, custom raw port/ Port9100, IPP/IPPS, FTP server, TELNET server, HTTP/HTTPS server, TFTP client en server, SMTP client, SNMPv1/v2c, ICMPv6, web services (print), CIFS client, SNTP client, LDAP
Paper input type	Paper tray
Total input capacity	520 sheets
Total output capacity	150 sheets
Maximum input capacity	1040 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	287 mm
