6 - 4
PARTS section 6
Parts List for Figure 2
Ref Part no. Description Quantity
1 401181 FRAME, MAIN 1
2 401185 HANDLE WELDMENT 1
3 (See Figure 3)
4 (See Figure 1)
5 401270 ROLLER, 12" 1
6 B8008 FLANGE, PRESSED STEEL 6
B8006 BEARING, CARTRIDGE 3
7 97-0508 CARRIAGE BOLT, 5/16 X 1 6
8 99-E38 LOCKNUT, NYLON 5/16 6
9 401121 AXLE, FRONT WHEEL 1
10 R1032 WHEEL, 8" X 3/4 BORE 2
11 85-SC12 SET COLLAR, 3/4" 2
12 D1129 SPROCKET 1
13 85-W0306 KEY, WOODRUFF 3/16 X 3/4 1
14 D1134 SPROCKET 1
15 85-W0306 KEY, WOODRUFF 3/16 X 3/4 1
16 114041 CHAIN, #40 ROLLER 34-3/4" W/O HALF LINK 1
17 81-076 HALFLINK, #40 1
18 81-056 CONNECTOR LINK, #40 1
19 D8036 CENTRIFUGAL CLUTCH 1
20 85-K0310 KEY, 3/16 X 3/16 X 1-1/4 1
21 401197 KICKSTAND, LOWER 1
22 5401194 KICKSTAND, RH UPPER 1
5401196 KICKSTAND, LH UPPER 1
24 97-0622 (REF) CARRIAGE BOLT, 3/8 X 2-3/4 (SEE FIG. 5, REF. 12)
25 99-E38 LOCKNUT, NYLON 5/16 4
26 90-0814 BOLT, 1/2 X 1-3/4 2
27 401090 SPACER, KICKSTAND 2
28 99-E41 LOCKNUT, NYLON 1/2 2
29 97-0506 CARRIAGE BOLT, 5/16 X 3/4 6
30 401259 WASHER, ECCENTRIC 2
31 99-E38 LOCKNUT, NYLON 5/16 2
32 S2001 SPRING, EXTENSION 1
33 401214 BRACKET, UPPER MOUNTING 1
34 90-0610 BOLT, 3/8 X 1-1/4 2
35 96-06 LOCKWASHER, 3/8 3
36 95-05 FLAT WASHER, 5/16 SAE 4
37 95-12 FLAT WASHER, 3/4 SAE 2
39 (See Figure 4 or 4A) 1
40 (See Figure 6) 1
41 96-05 LOCKWASHER, 5/16 1
42 94-05 FLAT WASHER, 5/16 USS 1
43 91-0506 BOLT, 5/16 X 3/4 NF 1
44 90-05010 (REF) BOLT, 5/16-18 X 1-1/4 (SEE FIG. 3, REF. 17)
45 95-05 (REF) FLAT WASHER, 5/16 SAE (SEE FIG. 3, REF. 23)
46 99-E12 (REF) FLANGE NUT, 5/16 (SEE FIG. 3, REF. 18)
47 99-11 BOLT, 3/8 X 1 SHCS 1
