PARTS section 6
Parts List for Figure 3
Ref
Part no.
Description
Quantity
1
401150
FRAME, DEPTH ADJUSTMENT
1
2
401053
BLADE, LH (13" WIDE)
1
3
401054
BLADE, RH (13" WIDE)
1
4
A41041
KIT, KNIFE ARM W/BUSHINGS (Includes Ref. 5)
2
5
L5011
BUSHING, 7/8"ID X 1"OD X 1"
2
6
401120
SHAFT, BLADE ARM PIVOT
1
7
29-010
GREASE FITTING, 1/4-28 SHORT
2
8
401149
SHAFT, CONNECTING ROD
2
9
A41003
ROD, CONNECTING
2
10
B2011
BEARING, BALL (17MM)
2
11
F2056
FLAT WASHER, 5/16"ID X 7/8 OD X .125 THICK
2
12
F1076
WASHER, DISC LOCK (pair)
2
13
90-0406
BOLT, 1/4 X 3/4
2
14
F5714
BOLT, WHEEL 1/2 UNF X 1-1/4
4
15
F5011
NUT, NYLON LOCK 1/2 THIN NF
4
16
5401189
SLIDE, CUTTING DEPTH ADJUSTMENT
1
17
90-0510
BOLT, 5/16 X 1-1/4
1
18
99-E12
FLANGE NUT, 5/16
1
19
F020840
BOLT, CARRIAGE. 1/2 X 4
1
20
5401188
CLAMP, CUTTING DEPTH ADJUSTMENT
1
21
5401209
SPACER
2
22
5401323
HANDLE
1
23
95-05
FLAT WASHER, 5/16 SAE (Serial No. 4050 - )
5
24
F9023
KIT, U-BOLT (Includes Ref. 27)
2
25
85-SS09
SET SCREW, 5/16 X 3/8 SKTHD
2
26
L5001
WASHER, THRUST 7/8"ID X 1-3/4"OD
1
27
93-05
NUT, 5/16 NF (Serial No. 1000 - 4049)
4
99-A05NF
LOCKNUT, 5/16 STOVER NF (Serial No. 4050 - )
4
28
401333
CLIP, RETAINER (Serial No. 4336 - )
1
6 - 6
