6 - 8
PARTS section 6
Parts List for Figure 4 (Serial No. 1000 - 4089)
Ref Part no. Description Quantity
401328 GEARBOX ASSEMBLY 1
1 5401028 CASE, GEAR LEFT SIDE 1
2 401235 CASE, GEAR RIGHT SIDE 1
3 A41005 GEAR, INTERMEDIATE 1
4 5401037 SHAFT, PINION 1
5 B2017 BEARING, BALL (12MM) 2
6 G1504 RETAINING RING, EXT. 7/8" DIA 4
7 G8033 KEY, WOODRUFF #606 3
8 5401030 GEAR, SPUR 2
9 401032 PLUG, FROST 2
10 H8026 PLUG, SOCKETHEAD 1/4" 2
11 E1030 SEAL, OIL 7/8 SHAFT X 1-3/8 2
12 L5012 BUSHING, 7/8ID X 1-1/8OD X 1 1
13 G8041 PIN, DOWEL: 1/4"OD X 1/2"LG 2
14 L5001 WASHER, THRUST 7/8"ID X 1-3/4"OD 2
15 95-14 FLAT WASHER, 7/8 SAE 1
16 H8064 PLUG, HEX HEAD VENT:-1/8NPT 1
17 90-0407 BOLT, 1/4 X 7/8 8
18 92-04 NUT, 1/4 8
19 F1076 WASHER, DISC LOCK 8
20 401096 SHAFT, INPUT GEAR 1
21 F2603 SET SCREW, 5/16 X 3/8 2
22 85-W0306 KEY, WOODRUFF 3/16 X 3/4 3
23 401031 SHAFT, OUTPUT GEAR 1
24 401155 SHEAVE, CRANKSHAFT DRIVE 2
25 D2320 SHEAVE, TAPER LOCK 7" 1
26 D2104 BELT, A20 2
27 81-A053 BELT, A53 1
28 G1504 RETAINING RING, EXT 7/8" DIA 1
29 L5001 WASHER, THRUST 7/8"ID X 1-3/4"OD 1
30 95-14 FLAT WASHER, 7/8 SAE 1
31 D3032 BUSHING, TAPER LOCK 1
