6 - 10
PARTS section 6
Parts List for Figure 4A (Serial No. 4090 - )
Ref Part no. Description Quantity
401328 GEARBOX ASSEMBLY (INCLUDES REF. 1-19) 1
1 87-003160 RIGHT HOUSING HALF 1
2 87-106781 GEAR 1
3 87-153411 BALL BEARING 3
4 87-600668 KEY 1
5 87-301432 SEAL 1
6 87-151282 BALL BEARING 1
7 87-106799 INTEGRAL SHAFT 1
8 87-620054 RETAINING RING 1
9 87-410019 PIPE PLUG (VENTED) 1
10 87-153437 BALL BEARING 1
11 87-301374 SEAL 1
12 87-620013 RETAINING RING 1
13 87-223173 SHAFT 1
14 87-153429 BALL BEARING 1
15 87-600056 KEY 1
16 87-106807 GEAR 1
17 87-106773 INTEGRAL SHAFT 1
18 87-003178 LEFT HOUSING HALF 1
19 87-410076 CAP SCREW 8
20 85-W0306 KEY, WOODRUFF 3/16 X 3/4 3
21 401155 SHEAVE, CRANKSHAFT DRIVE 2
22 85-SS09 SET SCREW, 5/16 X 3/8 SKTHD 2
23 D2104 BELT, A20 2
24 81-A052 BELT, A52 (SERIAL NO. 4090 - 4757) 1
81-A053 BELT, A53 (SERIAL NO. 4758 - ) 1
25 D2320 SHEAVE, TAPER LOCK 7" 1
26 D3032 BUSHING, TAPER LOCK 1
