6 - 12
PARTS section 6
Parts List for Figure 5
Ref Part no. Description Quantity
1 401245 LEVER, THROTTLE 1
2 G2323 PIN, SPRING TENSION-1/4 X 1-5/8 1
3 401244 CABLE, THROTTLE 1
4 F0061 WASHER, FLAT 147 ID X 5/16 OD 1
5 F0027 SCREW, ROUND HD #6-32 X 3/4 1
6 G1519 RING, EXTERNAL RETAINING 5MM 1
7 07-0407010 METRIC BOLT, M4-0.70 X 10 (HEX HEAD) 1
8 Z9004 CABLE CLAMP 1
9 401250 PIN, THROTTLE 1
10 30-037 WIRE TIE, T 50R 3/16 X 7-3/4 7
11 M5115 HANDLE GRIP 2
12 97-0622 CARRIAGE BOLT, 3/8-16 X 2-3/4 2
13 5401182 HANDLE, RACHET 4
14 KM99069 KNOB, HAND 2
15 94-06 F
LAT WASHER, 3/8 2
16 99-A06 LOCKNUT, STOVER 3/8 2
17 J0039 SWITCH, KILL (PRIOR TO SN 4480)(No longer available) 1
31-058 SWITCH, KILL (SN 4480 & UP) 1
18 F0331 SCREW, #10 X 1/2 2
19 A41018 WIRE, KILL SWITCH (16 GA. BLACK X 64-3/4" LONG) 1
20 30-025 WIRE TIE, 3/16 X 5-1/2 5
21 30-095 CONNECTOR, QUICK SPLICE 1
22 401185 HANDLE WELDMENT 1
23 REF GROUND WIRE, 1-3/4” LONG (SN 4480 & UP) 1
30-004A5 WIRE, 16 GA. BLACK 1
30-323 TERMINAL, #6 EYELET 2
30-324 TERMINAL, #8 EYELET 1
24 01-009 FLAT WASHER, #
8 SAE (SN 4480 & UP) 4
25 S2019 SPRING, EXTENSION 1
26 KM31006 RUBBER END CAP (Not Illustrated) 2
