6 - 14
PARTS section 6
Parts List for Figure 6
Ref Part no. Description Quantity
1 A41002 CRANKSHAFT ASSEMBLY (Includes Ref 2 - 14) 1
2 401021 HOUSING, CRANKSHAFT 1
3 401022 CRANKSHAFT 1
4 B2012 BEARING, BALL (35MM) 2
5 401023 SHEAVE, CRANKSHAFT 2
6 85-W0306 KEY, WOODRUFF 3/16 X 3/4 2
7 F1604 SCREW, HEX SOC SET 1/4 X 1/4 2
8 B2011 BEARING, BALL (17MM) 2
9 F1200 BOLT, 1/4 X 3/8 GR. 5 2
10 94-04 FLAT WASHER, 1/4 USS 2
11 90-1036 BOLT, 5/8 X 4-1/2 1
12 99-E42 LOCKNUT, NYLON 5/8 1
13 5401324 BOLT, ADJUSTMENT 1
14 99-E11 JAM NUT, 5/8 NF 1
