Brouwer MARK 2 - Page 37

6 - 16
PARTS section 6
Parts List for Figure 7
Ref Part no. Description Quantity
1 96-06 (REF) LOCKWASHER, 3/8 (SEE FIG. 2, REF. 35)
2 401319 GUARD, REAR 1
3 401314 GUARD, FRONT 1
4 90-0512 BOLT, 5/16 X 1-1/2 2
5 94-05 FLAT WASHER, 5/16 USS 4
6 99-K19 BOLT, FLANGE 5/16 X 3/4 2
7 99-E12 FLANGE NUT, 5/16 1
8 95-05 FLAT WASHER, 5/16 SAE 6
9 5401214 BRACKET, UPPER MOUNTING 1
10 401236 GUARD, REAR 1
11 401331 SHIELD, BELT (SERIAL NO. 4336 - ) 1
12 401211 GUARD, CHAIN 1
13 99-K28 BOLT, FLANGE 5/16 X 1/2 6
14 90-0610 (REF) BOLT, 3/8 X 1-1/4 (SEE FIG. 2, REF. 34)
