Replacement Parts
51
240/165 HP Gearbox (continued)
Ref. No. Part No. Description
1 T5-039
T5-039-20
Shaft, input - 1-3/4” x 6 spline
Shaft, input - 1-3/4” x 20 spline
2 T5-036 Plate, front input
3 T5-066 Seal, input
4 T5-047 Gasket, input
5 T5-064 Bearing set, front input
6 T5-069A
T5-076S
Gear set - 540 RPM
Gear set - 1000 RPM
7 T5-060 Bearing set, rear input
8 BM-108 Shim Kit, 1 each of 0.2MM - 0.25MM - 0.3MM - 0.4MM Shims
10 T5-037 Plate, rear input
11 T5-035 Plate, top
12 T5-050 Bolt, Hex Head (M10 x 20) for Top Plate
13 T5-038 Housing, gearbox
14 T5-068 Plug, vent/dip
15 T5-044A Nut, output shaft, top
16 T5-045
T5-076A
Spacer, output, 540 RPM (above gear)
Spacer, output, 1000 RPM (below gear)
18 T5-061 Bearing set, upper output
19 T5-062 Bearing set, lower output
20 T5-065 Seal, output
21 T5-048 Protector, seal
22 T5-040 Shaft, output
23 T5-054A Nut, anged, castellated
24 T5-052 Pin,cotter
Not shown T5-074 Gearbox - 540 RPM
Not shown T5-074B Gearbox - 1000 RPM
Not shown T5-051 Bolt, front & rear input plate
Not shown TC2-002 Bolt, Grade 8, sq. head, 3/4” x 3-1/2”
Not shown T5-LUBE Gearbox oil (1 QT)
Not shown LT-120-1 Vent, breather, top plate
We have a section on our website: www.brownmfcorp.com, under Maintenance Bulletins,
that is a detailed procedure for the disassembly and reassembly of this gearbox.
