BROWN 2000 Series - Page 52

145 HP Blade Carrier Assembly
Replacement Parts
52
Ref. No. Part No. Description
1 T5-042
Blade carrier hub (sold only with item 4)
2 T5-078
Blade carrier star plate (sold only with item 4)
4 TC2-145-5
TC2-145
Blade carrier assembly (includes items 1, 2, 4, 5) - 5’ models
Blade carrier assembly (includes items 1, 2, 4, 5) - 6’ models
6 T5-052 Cotter pin
7 T5-054A Nut, Splined w/ ange (Castellated) Blade Carrier
8 TC-133KL
TC2-005-KIT
Blade bolt kit - 5’ models (matched bolt & nut) right handed threads
Blade bolt kit - 6’ models (matched bolt & nut) left handed threads
* Both come with copper antiseize, apply liberally to threads of bolt.
9 UK-905
UK-120
Blade - 5’ models
Blade - 6’ models
10 TC-Wrench Socket wrench
11 T-2600-001 Removal tool
12 TC2-006S 120/145 Blade bolt socket
13 T5-054AS 145/165/240 Blade bar socket
10
13
12
11
