BROWN 2000 Series - Page 53

Replacement Parts
53
240/165 HP Blade Carrier Assembly
Ref. No. Part No. Description
1 T5-000A Blade bar assembly
2 T5-042
Blade bar hub (sold only with Item 1)
3 T5-078A
Reinforcement plate, large (sold only with Item 1)
4 T5-078C
Reinforcement plate, small (sold only with Item 1)
5 T5-005T Blade bar bushing (4 req.)
6 T5-054A Nut, Splined w/ ange (Castellated) Blade Carrier
7 T5-052 Cotter pin
8 T5-001KIT Blade bolt w/ nut sold in kits only (4 req.) Left Handed Threads
Comes with copper antiseize, apply liberally to threads of bolt.
9 UK-165 Blade, round back (4 req.)
10 T-2600-001 Removal tool
11 T5-004BS 165/240 Blade bolt socket
12 T5-054AS 145/165/240 Blade bar socket
13 TC-Wrench Socket wrench
10
13
12
11
10
