Assembly
16
Step: 6
Locate and mount tongue into the front 3-point hitch using the CAT II hitch pins. Mount tongue
brace into top link positions and tongue height bracket on tongue assembly. This adjustable height
bracket will need to be adjusted to match your tractor’s draw bar height, allowing the tongue to stay
in a level position during operation.
Step:7
Find and mount tongue jack onto pivot tube welded to tongue. Continue to route hydraulic hoses
down the tongue and secure through welded U-bolt mounts and straps.
