position and slowly pull rearward on the slide to extract and eject the
cartridge from the chamber.
INSPECT THE ACTION AND CHAMBER TO BE SURE NO LIVE CARTRIDGE
REMAINS IN THE PISTOL.
With the magazine removed, the stop open
latch must be raised manually to hold the slide open.
SIGHT ADJUSTMENT
BUCK MARK AND MICRO BUCK MARK
All Buck Mark pistols are equipped with Browning Pro Target Sights.
These precision rear sights are screw adjustable with 16 clicks per
revolution on both the elevation and windage screw.
When performing all sight adjustment procedures,
MAKE SURE YOUR
PISTOL IS FULLY UNLOADED.
Remove the magazine, check the chamber
and point the muzzle in a safe direction.
WINDAGE: To move the point of impact to the right, turn the screw
located on the right side in a clockwise direction (Figure 9).
To move the point of impact to the left, turn the screw in a counter-
clockwise direction.
ELEVATION: To raise the point of impact, turn the elevation screw,
located just forward of the rear sight notch, in a counterclockwise
direction. To lower the point of impact, turn the elevation screw in a
clockwise direction (Figure 10).
13
FIGURE 9
To adjust windage, turn the screw located on
the right side of the sight.
FIGURE 10
To adjust elevation, turn the elevation screw
located just forward of the rear sight notch.
