REMOVING THE SIGHT HOODS: If it becomes necessary
to remove the sight hoods,
TAKE SPECIAL CARE TO AVOID MARRING THE
FINISH OF YOUR BUCK MARK PISTOL.
The front hood can be removed by sliding it forward off the sight
base. The rear hood is removed by inserting your index finger inside
the hood and pulling up and outward on one side of the hood until
it comes off. (Replace in reverse order.)
DISASSEMBLY
BUCK MARK,BUCK MARK PLUS & BULLSEYE MODELS
CAUTION: WEAR EYE PROTECTION WHEN DISASSEMBLING AND CLEANING
YOUR PISTOL TO PREVENT THE POSSIBILITY OF SPRINGS, SPRING-
TENSIONED PARTS, SOLVENTS OR OTHER AGENTS FROM CONTACTING YOUR
EYES. BE CERTAIN YOUR PISTOL IS UNLOADED. REMOVE THE MAGAZINE AND
INSPECT THE CHAMBER. KEEP THE MUZZLE POINTED IN A SAFE DIRECTION.
1 Be certain the muzzle is pointed in a safe direction. Remove the
magazine. Draw the slide rearward and lock open with the stop open
latch. Visually inspect the chamber to be certain it is empty. Release
the stop open latch and allow the slide to close.
2 Remove the two sight base screws and lift the sight base – with sight
attached – from the frame. Be careful not to lose the two lockwashers
(Figure 13).
CAUTION: WHEN REINSTALLING THE REAR SIGHT BASE
15
FIGURE 13
Lift the sight base from the frame.
FIGURE 14
Lift the recoil rod upward from the slide.
