3
screws enough to allow movement, as completely removing the
two screws could cause the loss of small parts contained in the rib
pivot point assembly.
Notice! fAiLurE to LooSEn Both of thESE ScrEWS BEforE AnY
furthEr AdjuStmEnt crEAtES A condition in Which thE riB iS
not ALLoWEd to PiVot or moVE VErticALLY And cAn rESuLt in
BEndinG thE riB.
2 The point of impact adjustment is on the front end of the rib and
is adjusted by a spring detent thumbscrew located between the rib
and the barrel near the muzzle
(Figure 2). Turn the thumbscrew
clockwise to lower the front of
the rib. Turn the thumbscrew
counterclockwise to raise the
front of the rib.
3 The sight picture is adjusted
with the rear adjustment screw
located on the monoblock
just above the chamber area
(Figure 3). It is a spring detent
screw, giving audible and tactile
mAKE SurE of AdEquAtE VEntiLAtion in thE ArEA thAt You
diSchArGE A firEArm. LEAd ExPoSurE cAn occur from
diSchArGinG firEArmS in PoorLY VEntiLAtEd ArEAS, cLEAninG
firEArmS or hAndLinG Ammunition.
Lead is a substance that has been known to cause birth defects,
reproductive harm and other serious injury. Wash hands thoroughly
after exposure to ammunition or after cleaning a firearm.
WEAr EYE ProtEction WhEn diSASSEmBLinG And cLEAninG Your
ShotGun to PrEVEnt SPrinGS, SPrinG-LoAdEd PArtS, SoLVEntS or
othEr AGEntS from contActinG Your EYES, rESuLtinG in injurY.
BROWNING CYNERGY CLASSIC TRAP
UNSINGLE SHOTGUN RIB
The Browning Cynergy Classic Trap Unsingle Shotgun offers an
adjustable rib to allow you to fine-tune the angle of the rib for point
of impact and sight picture. This perfect bead alignment promotes
consistent head position and eye-to-rib alignment, resulting in
improved shooting performance and higher scores.
MAKING RIB ADJUSTMENTS
BEforE AttEmPtinG to AdjuSt thE riB on thE BroWninG cYnErGY
cLASSic trAP unSinGLE ShotGun, PLAcE thE “SAfEtY” in thE on
SAfE PoSition. oPEn thE Action And mAKE cErtAin Your ShotGun
iS comPLEtELY unLoAdEd. KEEP thE muzzLE PointEd in A SAfE
dirEction. fAiLurE to foLLoW thESE WArninGS couLd rESuLt in
SEriouS injurY or dEAth.
Notice! thE uPPEr chAmBEr of thE monoBLocK iS PLuGGEd
for SAfEtY rEASonS to PrEVEnt inSErtion of A ShELL into
thAt chAmBEr.
1 Use a 2mm Allen wrench to loosen both the screws at the rib pivot
point, located at the junction of the rib and the barrel assembly
just above the front of the forearm (Figure 1). Only loosen the
fiGurE 1
Loosen both screws at the rib pivot point.
fiGurE 2
Turn the thumbscrew to raise or lower the
front of the rib.
fiGurE 3
Turn the screw to raise or lower the rear of
the rib.
