3 Engage the hidden screws with the screwdriver. Turn clockwise
until the screws are tight in the stock. Do not over tighten
the screws.
TRIPLE TRIGGER
™
SYSTEM
before Changing triggers or performing adjustment
proCedures, plaCe the “safety” in the on safe position. open
the aCtion and make Certain the Chambers are unloaded. keep
the muZZles pointed in a safe direCtion. failure to follow
these warnings Could result in serious injury or death.
The Triple Trigger System has three interchangeable trigger shoes with
different surfaces: wide with checkered surface, wide with canted
smooth surface and narrow with smooth surface. Each trigger shoe is
adjustable to three positions for length of pull. Please heed all safety
warnings, cautions and procedures found in this owner’s manual
when adjusting or installing trigger shoes.
REMOVING THE TRIGGER
Before you begin to remove the trigger, place the “safety” in the
rearward, on safe position to prevent dry firing your shotgun as you
are changing/adjusting trigger shoes.
All Cynergy target models are supplied with three different styles
of trigger shoes. To remove the trigger shoe, loosen the center screw
with the provided 2mm (
5
/64") Allen wrench (Figure 23). Loosen the
screw so the trigger shoe slides easily on the trigger plate. Keep the
screw threaded at least one thread into the trigger shoe so the screw
is not lost.
Slide the trigger shoe forward to the end of the trigger plate. Press the
rearward end of the trigger plate down with your finger and gently
slide the trigger shoe off the trigger plate.
To replace the trigger shoe, press the rearward end of the trigger plate
and slide the trigger shoe down the side grooves of the plate.
CHANGING THE LENGTH OF PULL
With the trigger shoe loosely on the trigger plate, select the length
of pull by lining up the notch on the right side of the trigger shoe
with one of the three notches on the right side of the trigger plate
(Figure 24). Make sure you line up the notches so you do not mar
the trigger plate. When the notches are properly aligned the screw on
the trigger shoe will seat in one of three recesses on the bottom of the
trigger plate.
Use the provided 2mm (
5
/64") Allen wrench to tighten the screw on the
trigger. Be certain the trigger shoe is secure before firing, and
periodically check the shoe for any looseness as part of your cleaning
and general maintenance procedures.
CLEANING AND MAINTENANCE SUGGESTIONS
NOTICE! please take note of the following information before
Cleaning your firearm.
CLEANING PARTS WITH SPECIAL FINISHES
Be especially careful when cleaning firearms with camouflage,
Dura-Touch
®
Armor Coating and other special finishes. Always
prevent these surfaces from coming in contact with cleaning solvents,
figure 23
Remove the trigger retaining screw.
figure 24
Line up the notch on the right side of the
trigger shoe with one of the three notches on
the right side of the trigger plate.
