11
do not dePend on the red color alone to indicate your
firearm’s safety status. time, eXPosure to the elements, and the
aBrasive action of cleaning agents can erase it. failure to
follow this warning could result in serious injury or death.
COCKING INDICATOR
Below the bolt shroud and ahead of the “safety” is a serrated cocking
indicator. The indicator is painted red. When the rifle is cocked it
may be readily felt with the thumb as well as easily seen with a quick
glance downward (Figure 4). When the rifle is fired, the cocking
indicator retracts into the bolt shroud and cannot be seen or felt.
do not dePend on the red color alone to indicate your
firearm’s safety status. time, eXPosure to the elements, and the
aBrasive action of cleaning agents can erase it. failure to
follow this warning could result in serious injury or death.
BOLT UNLOCK BUTTON
The bolt unlock button on the X-Bolt rifle is located on the upper part
of the bolt handle (Figure 5). The bolt unlock button works in
figure 4
Location of the cocking indicator, shown in the
cocked position.
figure 5
Location of the bolt unlock button.
