STEP 11
Assemble the Big Roof Small
Beam(N1)&(N2) to Beam Connector 1(P)
with bolts(H1), Assemble the Big Roof Small
Beam(N1)&(N2) to Beam Connector 2(Q)
with bolts(H1), tighten by wrench (HW1).
